Hikvision DS 2CE5AH0T ITPF 5MP 3.6MM

Brand – Hikvision

Model – DS-2CE5AH0T-ITPF

Image Sensor – 5MP CMOS image sensor

Signal System – PAL/NTSC

Switchable – TVI/AHD/CVI/CVBS

Effective Pixels – 2560 (H) x 1944 (V)

Min. illumination – 0.01 Lux@(F1.2,AGC ON), 0 Lux with IR

Shutter Time – PAL: 1/25 s to 1/50, 000 s , NTSC: 1/30 s to 1/50, 000 s

Lens – 3.6MM Angle 80.1°

Lens – M12

Day & Night – IR cut filter

Angle Adjustment – Pan 0° to 360°, Tilt: 0° to 180°, Rotation: 0° to 360°

Synchronization – Internal synchronization

Video Frame Rate – PAL: 5 MP@20fps, 4 MP@25fps, 1080p@25fps , NTSC: 5 MP@20fps, 4 MP@30fps, 1080p@30fps

HD Video Output – 1 analog HD output

Operating Conditions – -40 °C to 60 °C (-40 °F to 140 °F), Humidity 90% or less (non-condensation)

Power Supply – 12 VDC±15%

Power Consumption – Max. 4.3 W

Protection Level – IP67

IR Range – Up to 20m

White Balance – ATW/MWB

BLC – Support

DWDR (Digital Wide Dynamic Range) – Support

Functions Brightness, Sharpness, DNR , Mirror, Smart IR
